CONNECTIVITY
-Connectivity 2.4 GHz Wi-Fi 802.11N
-Security Compatibility: -WEP -WPA -WPA2 -PSK 64 -WPA -PSK -WPA2 -128-bit -WPS
Supports devices with Bluetooth 4.0 and 150Mb high-speed signal. Backwards compatible with Bluetooth such as V3.0, V2.1, V2.0 and V1.2
COMPACT DESIGN
It doesn't need extra wires and has no protruding antennas, nor does it require you to operate it in any way; just plug it in and connect.
BIG RANGE
Its WiFi connection has a range of 10 meters indoors and 20 meters outdoors, and an extended range of 25.3 meters for Bluetooth.
COMPATIBILITY AND SUPPORT
Supports WiFi through Windows 7/8/10/11 and MacOS, supports Bluetooth through Windows 7/8/10 and 11.
| BLUETOOTH | 4.0 |
| INTERFACE | USB 2.0 |
| FREQUENCY RANGE | 2.4-2.4835 GHZ |
| TRANSMISSION DISTANCE | INDOOR 32 FT , OUTDOOR 65 Ft |
| RF POWER | 10dBm |
| ANTENNA GAIN | Built-in antenna 1 – 2 dBi |
| ENERGY | 100 mA - 200 mA (BT + WIFI)CURRENT WILL CHANGE WITH WORKING MOD |
| SUPPORTED OS | WINDOWS 7 / 8 / 10 |
| ADAPTER | WIFI 802.11N |
| TRANSFER SPEED | 150 Mbps |
| STANDARDS | IEEE 802.1 IN, IEEE 802.11G, IEEE 802.11B |
| SECURITY | WEP/WPA/WPA2/WPA-PSK/WPA2-PSK 64/128 bit and WPS |
| OPERATING | FCC: 2412- 2462 MHz (CH1 CH11) |
| FREQUENCY | ETSI: 2412-2462 MHz (CH1 CH13) |
| RF FREQUENCY | 2412-2462 MHz (NORTH AMERICA) |
| RE POWER | 11N MODE: 13 dBm 11G MODE: 15 dBm 11B MODE: 18 dBm |
| LED STATUS | LINK STATUS ACTIVITY |
